Kicker KA46CXA3604 CX Series 4 Channel Class A/B 360W Car Amplifier

Kicker KA46CXA3604

Power your door speakers with the CX 360W 4 Channel Class A/B Amplifier. Offering variable bass boost, 12dB crossover, and compatibility with almost any radio, this amplifier optimizes sound quality and eliminates the need for converters. Its efficient heat sinks keep it cool while ensuring noise rejection. Plus, its compact and easy to install. Enjoy an immersive audio experience with this versatile amplifier.

The CXA360.4 Four-Channel Amplifier is built to power all your door speakers in a single, powerful package.

Using Class A/B power, this amp features a variable bass boost with KickEQ, giving you as much as a 6dB of extra bump. A powerful 12dB crossover is also included, letting you quickly tune your system to perfection.

CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

Highly efficient heat sinks keep the amp cool with a sophisticated new look, while KICKER’s FIT+ (Fail-safe Integration Technology-PLUS), gives you outstanding noise rejection – even with premium factory audio systems.

This CX-Series Amplifier delivers as much as 90 watts into four full-range channels, or 180 watts into two bridged channels. See below for more details.

Power Specification

• 90W x 4 @ 2Ω – 14.4V
• 65W x 4 @ 4Ω – 14.4V
• 180W x 2 @ 4Ω – 14.4V (bridged)

Features

• Class A/B full-range channels
• Three-second turn-on/off delay to eliminate unwanted interference
• Variable 12dB crossovers provides control to dial in perfect sound
• KickEQ™ 6dB variable bass boost for those additional low frequencies
• FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
• Accepts up to 40-volt input signal
• Small footprint for easier installation
• Vertical mounting hardware included for another unique look
• Compatible with CXARC Remote Bass Control (AMP2 must be in LO-PASS X-OVER mode)

Specifications

• RMS Power @ 14.4V
  • 65W x 4 @ 4Ω
  • 90W x 4 @ 2Ω
  • 180W x 2 @ 4Ω Bridged
• Output Channels 4
• Voltage (V) 12
• Class A/B
• Features
  • KickEQ Bass Boost
  • FIT+ Technology
• Fuse Rating (A) 40A
• Cable Gauge (AWG) 8
• Amp Turn-On
  • DC Offset
  • 12V
• Frequency Response (Hz) 10-20k
• Signal-to-Noise Ratio (dB) 95
• Filter
  • High-Pass
  • Low-Pass
• Controller
• CXARC (Sold Separately)
• Input Channels
  • 2
  • 4
• Input Type
  • High Level
  • Low Level
• Input Sensitivity Low Level 125mV-5V
• Input Sensitivity High Level 250mV-10V
• Height (cm) 5.9
• Width (cm) 32
• Depth (cm) 17
• Colour Black
